Want to order a Velux Sun Tunnel? Have questions about Velux Sun Tunnels? Please fill out the form below and a Herman’s representative will contact you soon.
Velux | Skylights & Sun Tunnels
Click to Call: 1-888-243-7626
The No Leak Skylight | No leak promise | No worries
General Details
Skylights & Sun Tunnels
Skylights
Fixed Curb Mounted Skylights
| FCM Size Code | *1430 | *1446 | 2222 | *2230 | *2234 | 2246 | *2270 | *3030 | *3046 | *3434 | *3446 | *4646 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inside curb (W"xH") | 14.5 x 30.5 |
14.5 x 46.5 |
22.5 x 22.5 |
22.5 x 30.5 |
22.5 x 34.5 |
22.5 x 46.5 |
22.5 x 70.5 |
30.5 x 30.5 |
30.5 x 46.5 |
34.5 x 34.5 |
34.5 x 46.5 |
46.5 x 46.5 |
|
| Outside curb (W"xH") | 17.5 x 33.5 |
17.5 x 49.5 |
25.5 x 25.5 |
25.5 x 33.5 |
25.5 x 37.5 |
25.5 x 49.5 |
25.5 x 73.5 |
33.5 x 33.5 |
33.5 x 49.5 |
37.5 x 37.5 |
37.5 x 49.5 |
49.5 x 49.5 |
|
| Maximum skylight clearance (W"xH") | 18.625 x 34.625 |
18.625 x 50.625 |
26.625 x 26.625 |
26.625 x 34.625 |
26.625 x 38.625 |
26.625 x 50.625 |
26.625 x 73.625 |
34.625 x 34.625 |
34.625 x 50.625 |
38.625 x 38.625 |
38.625 x 50.625 |
50.625 x 50.625 |
|
*Please ask a Herman’s representative about other models and styles from Velux!
Fixed Deck Mounted Skylights
| FS Size Code | *A06 | *C01 | *C04 | *C06 | *C08 | *C12 | D26 | D06 | *M02 | *M04 | *M06 | *M08 | *S01 | *S06 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside frame (W"xH") | 15.25 x 46.25 |
21.5 x 27.375 |
21.5 x 38.375 |
21.5 x 46.25 |
21.5 x 54.063 |
21.5 x 70.75 |
23.25 x 23.438 |
23.25 x 46.25 |
30.563 x 30.5 |
30.563 x 38.375 |
30.563 x 46.25 |
30.563 x 54.063 |
44.75 x 27.375 |
44.75 x 46.25 |
|
| Rough opening/ Finished frame (W"xH") | 14.5 x 45.75 |
21 x 26.875 |
21 x 37.875 |
21 x 45.75 |
21 x 54.438 |
21 x 70.25 |
23.25 x 23.438 |
23.25 x 46.25 |
30.063 x 30 |
30.063 x 37.875 |
30.063 x 45.75 |
30.063 x 54.438 |
44.25 x 26.875 |
44.25 x 45.75 |
|
*Please ask a Herman’s representative about other models and styles from Velux!
The Benefits of a Fixed Skylight
- 1Clean, Quiet and Safe GlassSilicon dioxide makes Neat® glass exceptionally smooth. In fact, it’s much smoother than ordinary glass so water disperses evenly (sheets off), and evaporates quickly, greatly reducing water spotting. Reduce unwanted outside noise by up to 25% less than a standard double pane glass, and up to 50% less than a plastic skylight.
- 2DaylightAdding daylight to a home is essential to health and well-being.
- 3No Leak PromiseThe No Leak Skylight carries a 10-year installation warranty, plus 20 years on glass, 10 years on product, and 5 years on blinds and controls.
Sun Tunnels
Have questions, want to purchase one of the above products?
Please fill out the form below and a Herman’s representative will get back to you shortly.
Columbia | Skylights & Sun Tubes
For over sixty years Columbia has been the leading Canadian Manufacturer of skylight and solarium systems. With an immaculate track record of providing top quality products at an affordable price, Columbia skylights is the brand of choice for architects, roofers, and DIY homeowners.
